3.4

Water supply

The massage unit must be filled with normal mains water without additives.
Always comply with local regulations when connecting to the public water
supply mains.
Water supply and cooling conditions

Permissible water pressure
(water inlet):

Maximum cooling water temperature:
The device may only be operated with the pressure hose included in the
scope of delivery.
 Pressure hose 90906-.. (10 m, 3/8");
Inlet: 1.5 MPa (15 bar) operating pressure

Hose 50909-.. (10 m, 1/2"); outlet
3.5

Test run/Commissioning


Has it been filled with sufficient water?
 If daily operation will be more than 1 hour at maximum pressure: has a
cooling system been attached?
 Is the heating connected up?
 Are you sure that there are no leaks coming from the tank or pump?
If all questions were answered with 'Yes', then you can start the test run or
operate the unit.
– Switching the unit on – see operating instructions.
3.6

Maintenance

Remount any protective devices (e.g. safety switch) after completing work.
WARNING!
Use only genuine spare parts of the same type! The use
of other parts voids the CE conformity! Any liability is
excluded in the case of damage or injury proven to be the
result of the use of non-genuine spare parts.
Information for service staff
0.8 MPa (8 bar)
16 °C
