To enter the language editing mode, press the
and decrease ( ) keys. The selection is confirmed by pressing the enter (
denied display.
Press the key for the system to display the menu page.
Using the Page Up and Page Down

11 TIME BAND MENU

PROGRAM DISPLAY PAGE

There are 5 programs (scenarios) in the application of the VMF-RCC panel, which can be associated with various components of the system (fan coils, chillers, recovery units)
and just one program for DHW management.
There are two time periods in all programs in which the switch-on and switch-off time can be set.
On 1
00:00
That described below can be set in programs P1, P2, P3, P4:
— a desired room set for each time period;
— two different functioning profile managements (ECO or COM) for fan coils.
ECO (economy) mode for fan coils
Fancoil OFF
00:00
COM (comfort) mode for fan coils
1
00:00
1 SetPoint fancoil specific of the area
2 SetPoint fancoil T SET 1
3 SetPoint fancoil specific of the area
4 SetPoint fancoil T SET 2
5 SetPoint fancoil specific of the area
Please note that the user can edit the set point transmitted to several fan coils (through user interface VMF-E2, VMF-E4) by +/- 3°C or +/- 6°C.
For the proper functioning determined by the time period to be associated with the fan coils with MZC plenum, the Setpoint and the functioning mode must be locked in the
areas concerned.
23/03 – VMF-RCC_UN50_01
key. This status is highlighted when no string is displayed. To change the type of idiom, just act on the increase (
keys, scroll the pages contained in the sub-menu.
TIMEZONE 1
O 1
Fancoil ON Fancoil OFF
TIMEZONE 1
TSET 1
On 1 O 1
2
TIMEZONE 1
TSET 1
On 1 O 1
) key, while the effective memorisation in eeprom is highlighted by the disappearance of the
TIMEZONE 2
On 2
Fancoil ON
TIMEZONE 2
TSET 2
On 2
3 4
TIMEZONE 2
TSET 2
On 2
O 2
Fancoil OFF
O 2
24:00
5
O 2
24:00
)
24:00
