1
1 Key to enable the "Force Off Machine" function

The external air probe considered with the Multicontrol system is the one in the chiller/heat pump #1.
2
1
5
3 4
1. Boiler enabled
2. Heat pump enabled
3. T Force Off
4. T Force Off + 1,5°C
5. Tae
To enter the "Force Off Machine temperature" editing mode, press the key. This status is highlighted when no parameter is displayed. To change the value, act on the
increase ( ) and decrease ( ) keys. The data is confirmed by pressing the enter ( ) key and it is actually stored in the EEPROM module when the denied display
disappears.
Press the key for the system to display the menu page.
Using the Page Up and Page Down keys, scroll the pages contained in the sub-menu.

CHRONOTHERMOSTAT ENABLING PAGE FOR HEAT PUMP/CHILLER

This page can be used to enable/disable the "chronothermostat" functioning of the panel for controlling the heat pump or a chiller and select a daily hourly program.

CHRONOTHERMOSTAT FUNCTION FOR HEAT PUMP

For particular systems such as radiating floors or heating radiators, switch-on/off of the heat pump can be controlled by management of the chronothermostat implemented
in the panel. This functionality is enabled only if the following condition is satisfied:
— There are no fan coils connected to the RS485 network in the system.
— The production of domestic hot water in the system is not managed through the MultiControl system
To access the parameters that specify this functioning, just press the key (only visible in the conditions listed above), available in the "Chiller" and "Force Off Machine"
pages.
23/03 – VMF-RCC_UN50_01 49
