ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
Byte-Offset
8
14
46
48
56
68
100
102
110
122
154
156
164
176
208
210
218
230
262
264
272
284
316
318
326
338
370
372
380
392
424
426
434
Tabelle 8.33
Beispiel
Prozessdaten-Images mit modifizierten Datengrößen
Die Eingangs- und Ausgangs-Datengrößen der IO-Link-Ports und das Vorhandensein des
Extended Status können durch die Konfigurationsgruppe modifiziert werden. Sie können ent-
scheiden, welche Daten auf die Prozessdaten abgebildet werden. Die folgenden Konfigurati-
onstabellen bieten Ihnen ein Beispiel und eine Übersicht möglicher Datenstrukturen und Byte-
Offsets für Eingangs- und Ausgangsdaten:
92
Input-Daten
IO-Link diagnostics, 6 bytes
IO-Link port 1 data, status, 32 bytes
IO-Link port 1 PQI, 2 bytes
IO-Link port 1 extended status, 8 bytes
IO-Link port 1 events, 12 bytes
IO-Link port 2 data, status, 32 bytes
IO-Link port 2 PQI, 2 bytes
IO-Link port 2 extended status, 8 bytes
IO-Link port 2 events, 12 bytes
IO-Link port 3 data, status, 32 bytes
IO-Link port 3 PQI, 2 bytes
IO-Link port 3 extended status, 8 bytes
IO-Link port 3 events, 12 bytes
IO-Link port 4 data, status, 32 bytes
IO-Link port 4 PQI, 2 bytes
IO-Link port 4 extended status, 8 bytes
IO-Link port 4 events, 12 bytes
IO-Link port 5 data, status, 32 bytes
IO-Link port 5 PQI, 2 bytes
IO-Link port 5 extended status, 8 bytes
IO-Link port 5 events, 12 bytes
IO-Link port 6 data, status, 32 bytes
IO-Link port 6 PQI, 2 bytes
IO-Link port 6 extended status, 8 bytes
IO-Link port 6 events, 12 bytes
IO-Link port 7 data, status, 32 bytes
IO-Link port 7 PQI, 2 bytes
IO-Link port 7 extended status, 8 bytes
IO-Link port 7 events, 12 bytes
IO-Link port 8 data, status, 32 bytes
IO-Link port 8 PQI, 2 bytes
IO-Link port 8 extended status, 8 bytes
IO-Link port 8 events, 12 bytes
