ICE11-8IOL-G60L-V1D
Inbetriebnahme bei PROFINET
Beispiel: "Read"-Daten nach "Reading"
Abbildung 10.42
Fehler-PDU für die "Read/Write"-Sequenz
Offset
0
2
3
Tabelle 10.8
Port-Fehler der Fehler-PDU
Coding
0x0000
0x0001 to 0x06FFF
0x7000
0x7001
0x7002
0x7003 to 0x7FFF
168
Parameter Inhalt
Port Error Error Codes detected by the Lin-
king Module or Client
Error Code IO-Link Error codes according
AL_Read/ AL_Write services
Additional Code IO-Link Error codes according
AL_Read/ AL_Write services
Port-Fehlercode
No error
Reserved
IOL_CALL conflict
Incorrect IOL_CALL
Port blocked
Reserved
Datentyp
Unsigned16
Unsigned8
Unsigned8
Definition Quelle
No error detected Server
– –
Inconsistent Header Server and/or Client
information
Inconsistent Header Server and/or Client
information (send-
/response)
Port temporary not Server
available
– –
