ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
IO-Link Port Settings Object 0xA3
Unterstützte Dienste:
• Get Attribute Single 0x0E
• Set Attribute Single 0x10
Class-Attribut, Instanz 0
Attribut
1
2
Tabelle 8.59
Instance-Attribut, Instanz 1 ... 8
Attribut
1
2
3
4
5
6
7
8
9
Name Zugang
Revision Get
Max. Instance Get
Name Zugang
1 Get, Set
Output Data Size
Input Data Get, Set
1<Default ¬¹ Font>
Size
Input Data Extensi- Get, Set
1<Default ¬¹ Font>
on
Output Data Swapping Get, Set
1<Default ¬¹ Font>
Mode
Output Data Swapping Get, Set
1<Default ¬¹ Font>
Offset
Input Data Swapping Get, Set
1<Default ¬¹ Font>
Mode
Input Data Swapping Get, Set
1<Default ¬¹ Font>
Offset
IOL Failsafe Get, Set
Port Mode Get, Set
Datentyp Beschreibung
UINT Revision of this object
UINT Maximum instance number of an
object currently created in this
class level of the device
Datentyp Beschreibung
SINT 0: No data
1: 2 Byte
2: 4 Byte
3: 8 Byte
4: 16 Byte
5: 32 Byte
SINT 0: No data
1: 2 Byte
2: 4 Byte
3: 8 Byte
4: 16 Byte
5: 32 Byte
SINT 0: No Data
1: Extended Status
2: Events
3: Extended Status + Events
SINT 0: Raw IO-Link Data
1 ... 16: 1 ... 16 WORD
17 ... 24: 1 ... 8 DWORD
SINT 0 ... 30 Byte
SINT 0: Raw IO-Link Data
1 ... 16: 1 ... 16 WORD
17 ... 24: 1 ... 8 DWORD
SINT 0 ... 30 Byte
SINT 0: Set Low
1: Set High
2: Hold Last
3: Replacement Value, transfer-
red via IO-Link Failsafe Parameter
Object
4: IO-Link Master Command
SINT 0: Deactivated
1: Manual, with validation and
backup config
2: Autostart, no validation and
backup config
