Pepperl+Fuchs ICE11-8IOL-G60L-V1D Handbuch Seite 215

ICE11-8IOL-G60L-V1D
IIoT-Funktionalität
CHANNEL Object
Name
name
type
type_text
config
config_text
inputState
outputState
forced
simulated
actuatorDiag
sensorDiag
maxOutputCurrent
_mA
current_mA
voltage_mV
Tabelle 12.24
1. producing data
2. = Pin 1
3. if current measurement is available
4. if voltage measurement is available
Datentyp Beschreibung
string Name of channel
number Hardware channel type as
number:
0 = DIO
1 = Input
2 = Output
3 = Input/Output
4 = IO-Link
5 = IOL AUX
6 = IOL AUX with DO
7 = IOL AUX with DO. Can
be deactivated.
8 = Channel not available
string Textual representation of the
channel type
number Current configuration of the
channel:
0 = DIO
1 = Input
2 = Output
3 = IO-Link
4 = Deactivated
5 = IOL AUX
string Textual representation of the
current config
boolean
Input data
boolean Output data bit to the physi-
cal output pin
boolean True, if the output pin of this
channel is forced
boolean True, if the input value to the
PLC of this channel is simu-
lated
boolean True, if the output is in short
circuit / overload condition
boolean
True, if the sensor supply
in short circuit / overload
condition
number Maximum output current of
the output in mA
number Measured current of the out-
put in mA
number Measured voltage of this out-
put in mV
Beispiel
1
bit to the PLC
2
is
3
4
215
