IIoT-Funktionalität
PORT Object
Name
port_type
iolink_mode
iolink_text
aux_mode
aux_text
cq_mode
iq_mode
port_status
ds_fault
ds_fault_text
device
diag
Tabelle 12.25
1. always on
2. can be controlled by cyclic data
DIAG Object
Name
error
source
eventcode
216
Datentyp Beschreibung
string Textual representation
of the IO-Link port
type
number Current port mode:
0 = Inactive
1 = Digital output
2= Digital input
3 = SIO
4 = IO-Link
string Textual representation
of the current port
mode
number Indicates the configu-
red mode for the Pin 2:
0 = No AUX
1 = AUX output
2 = Digital output
3 = Digital input
string Textual representation
of the current aux
mode
number Port mode according
to IOL specification
number Pin 2 mode according
to IOL specification
number Port status according
to IOL specification
number Data storage error
number
string Textual data storage
error
DEVICE Object IO-Link device para-
meters.
•
array of DIAG (n) Array of port related
events
Datentyp Beschreibung
number Error code
string Source of the current
error.
number Event code according
to IO-Link specifica-
tion
Beispiel
"Digital Input"
1
2
"AUX Output"
Null if no IO-Link
communication
active
Beispiel
"device"
"master"
