ICE11-8IOL-G60L-V1D
IIoT-Funktionalität
MQTT-Konfiguration
Element
mqtt-enable
broker
login
password
port
base-topic
will-enable
will-topic
auto-publish
publish-interval
publish-identity
publish-config
publish-status
publish-process
publish-devices
commands-allowed boolean
force-allowed
reset-allowed
config-allowed
qos
Tabelle 12.1
1. fett = Standard
198
Datentyp Beschreibung
boolean Master switch for the MQTT
client.
string IP address of the MQTT Bro-
ker
string Username for MQTT Broker
string Password for MQTT Broker
number Broker port
string Base topic
boolean If true, the device provides a
last will message to the broker
string The topic for the last will mes-
sage.
boolean If true, all enabled domains will
be published automatically in
the specified interval.
number The publish interval in ms if
autopublish is enabled. Mini-
mum is 250 ms.
boolean If true, all identity domain data
will be published
boolean If true, all config domain data
will be published
boolean If true, all status domain data
will be published
boolean If true, all process domain data
will be published
boolean If true, all IO-Link Device
domain data will be published
Master switch for MQTT com-
mands. If false, the device will
not subscribe to any command
topic, even if specific com-
mand topics are activated
below.
boolean If true, the device accepts
force commands via MQTT.
boolean If true, the device accepts
restart and factory reset com-
mands via MQTT.
boolean If true, the device accepts con-
figuration changes via MQTT.
number Selects the "Quality of Ser-
vice" status for all published
messages.
Beispiel
1
true / false
"192.168.1.1"
"admin"
Default: null
"private"
Default: null
1883
"iomodule_[mac]"
Default: "ice11"
true / false
Default: null
true / false
2000
true / false
true / false
true / false
true / false
true / false
true / false
true / false
true / false
true / false
0 = At most once
1 = At least once
2 = Exactly once
