ICE11-8IOL-G60L-V1D
IIoT-Funktionalität
Struktur
STANDARD Object
Name
name
order-id
fw-version
hw-version
mac
bus
failsafe
ip
snMask
gw
rotarys
ulPresent
usVoltage_mv
ulVoltage_mv
inputs
output
consuming
Datentyp Beschreibung
string Device name
string Ordering number
string Firmware version
string Hardwareversion
string MAC address of the
device
number 0 = No connection
1 = Connection with
PLC
number 0 = Normal operation
1 = Outputs are in fail-
safe
string IP address of the
device
string Subnet Mask
string Default gateway
array of numbers (3) Current position of the
rotary switches:
Array element 0 = x1
Array element 1 = x10
Array element 2 =
x100
boolean True, if there is a UL
voltage supply
detected within valid
range
number US voltage supply in
mV
number UL voltage supply in
mV (only available for
devices with UL sup-
ply)
array of numbers (2) Real state of digital
inputs
Element 0 = 1 Byte:
Port X1 Channel A to
Port X4 Channel B
Element 0 = 1 Byte:
Port X5 Channel A to
Port X8 Channel B
array of numbers (2) Real State of digita-
loutputs
Element 0 =1 Byte:
Port X1 Channel A to
port X4 Channel B
Element 0 = 1 Byte:
Port X5 Channel A to
port X8 Channel B
array of numbers (2) Cyclic data from PLC
to device
Beispiel
"ICE11-8IOL-G60L-
V1D"
"70146527"
"V.1.1.0.0 -
01.01.2021"
"V.1.00"
"3C B9 A6 F3 F6 05"
1
0
\[128,3\]
\[55,8\]
