ICE11-8IOL-G60L-V1D
IIoT-Funktionalität
Anwendungsbeispiele
Gesamtes Topic
[base-topic]/identity/gateway
[base-topic]/identity/#
[base-topic]/status/port/5
[base-topic]/+/port/2
[base-topic]/process/port/#
[base-topic]/config/#
Tabelle 12.5
Publish-Topic
Übersicht über alle Publish-JSON-Daten für die definierten Topics:
Identity/gateway
Eingabe
tbd
ordering_number
device_type
serial_number
mac_address
production_date
fw_name
fw_date
fw_version
hw_version
vendor_name
vendor_address
vendor_phone
vendor_email
vendor_techn_support
vendor_url
vendor_id
device_id
Tabelle 12.6
Config/gateway
Eingabe
fieldbus_protocol json_string
network_configu-
ration
Datentyp Umfang
profinet, ether-
net/ip, ethercat
json_string PN: dcp
EIP: stored_-
value, bootp,
dhcp
Beschreibung
Receive only indentity objects for the gateway
Receive all data related to the identity domain
Receive only status information for port num-
ber 5
Receive information of all domains for port
number 2
Receive only process data for all ports
Receive config data for the gateway and all
ports.
Datentyp
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_string
json_integer
json_integer
Standardwert Bemerkungen
