2.3 Configuration for GSM call-up connection
To see the status, use the command SCADASETTINGS.
Command
SETSCADACODE <access code>
SCADACODE <ON | OFF>
MODBUSADDR <1-247>
2.4 Configuration for GPRS connection
To see the status, use the command GPRSSETTINGS.
Command
APN <APN string>
USERNAME <alpha numeric
string>
PASSWORD <alpha numeric
string>
AUTHENTICATION <NORMAL |
SECURE>
CONNECTION <SERVER | CLIENT |
DISABLED>
GPRSROAMING <ON | OFF>
MODBUSPORT <port number>
GENIPROPORT <port number>
Description
Sets a four-digit SCADA access code. If SCADA access code
protection is set to ON (see below), the SCADA access code has to
be written in the Modbus register "ScadaPinCode" (Reg. 000011)
before data can be written to the CIM 25X.
For the use of SCADA access code protection, see the functional
profile and user manual for the product in question.
Sets SCADA access code protection to ON or OFF.
Default setting: OFF.
Normally, the Modbus address does not play any role in a GSM or
GPRS network, as the SIM card phone number or the assigned IP
address replaces the addressing mechanism. The default Modbus
address usually works fine, but it can be changed with this command
if required.
Default setting: 231.
Description
Set the Access Point Name (APN) according to the information from
your GPRS service provider.
Default setting: Empty.
Set the user name for the APN according to the information from
your GPRS service provider. In many cases, a user name will not be
necessary.
Default setting: Empty.
Set the password for login to the APN according to the information
from your GPRS service provider. In many cases, a password will not
be necessary.
Default setting: Empty.
Select this option for login to the APN according to the information
from your GPRS service provider. In many cases, it will not be
necessary to change the setting.
Default setting: NORMAL.
The CIM 25X only supports connection mode SERVER or
DISABLED.
DISABLED can be used as a simple way to disable the GPRS
connection without removing the settings in the APN string.
Default setting: SERVER.
This command makes it possible to enable and disable GPRS
roaming if roaming for GSM and SMS communication is enabled with
the command ROAMING.
Default setting: OFF.
It will only be necessary to change the default setting of the Modbus
port number in very special cases.
Default setting: 502.
Used for GPRS connection to a Grundfos PC Tool. It will only be
necessary to change the default setting of the GENIpro port number
in very special cases.
Default setting: 49152.
13
