26.

Transport, Storage

Crushing and shearing hazard for limbs
when unloading.
DANGER
Caused by collapsing or slipping
of the load.
Only unload the packing unit and
trans port to the installation site with
a forklift truck or pallet jack with a
sufficient. load capacity.
Only use hoists approved for the
total weight (straps, chains etc.).
Attach these so that the load cannot
slip(check the center of gravity of
the load).
Only secure individual components
to loadbearing parts.
Always lift vertically steadily and
without jerking.
Carry out a visual inspection before
offloading
Do not stand close to or underneath
swinging loads.
Constantly monitor the danger zone
when lifting or lowering.
Always transport hydraulic compo
nents empty of oil.
ATTENTION:
Lift components may be damaged
if offloaded incorrectly.
Do not damage plates on the
underside of the lift when lifting.
Several parts are inserted into the
compo nents,for example into the
columns. Off load these carefully
to prevent damage.
When offloading, proceed from top
to bot tom.
26.1 Transport
The lift is supplied in a packing unit (base unit) plus
a separate extension columns. The packing
unit comes with the following documentation:
• Transport description giving suitable
suspension points, total weight, centre of
gravity, required cable lengths, transport locks,
etc.
• List of all individual components included in
deliver y.
26.2 Offloading
1. Inspect the shipment for any shipping or
transport damage. Immediately report any
damage to your supervisor and to the transport
firm.
2. Transport the packing unit to the installation
site. This must conform to the approved
environmental conditions
3. Unfasten the transport locks for the large parts
on the front of the packing unit.
4. Offload the columns and column extensions
and set down carefully.
5. Remove all other components from the pallet
and set down carefully.
6. Inspect the supplied parts according to the
packing list provided.
7. Dispose of packaging in an environmentally
friendly manner, in compliance with the
regulations applicable in your country
26.3 Storage
Lift components must always be stored in a dry place
(no corrosion protection).
Recommended Storage Conditions
• Ambient temperature: Maximum 55°C
• Relative humidity,
condensation, at 20 °C
The manufacturer provides no warranty for corrosion
damage caused by incorrect storage.
0496-M005-0
30 % ... 95 % with
49
