1. Lift Location: Use architects plan when available to locate lift. Fig. 2a & Fig. 2b shows dimensions
of a typical bay layout.
WARNING
DO NOT install this lift in a pit or depression due to fire or explosion risks.
A POWER UNIT HEIGHT
B LIFTING HEIGHT W/ 65mm EXTENSION
C MIN. LIFT HEIGHT
MIN. LIFT HEIGHT W/ 65mm ADAPTER
D OVERALL FLOOR WIDTH
E INSIDE COLUMNS
F WIDTH BETWEEN CARRIAGES
G HEIGHT OVERALL
MIN. FLOOR CEILING HEIGHT
H FLOOR TO OVERHEAD SWITCH
I DRIVE THRU CLEARANCE
J MINIMUM TO NEAREST OBSTRUCTION
K MINIMUM TO NEAREST OBSTRUCTION
L MINIMUM TO NEAREST OBSTRUCTION
NOTES:
1.) ALL HEIGHT DIMENSIONS ARE WITHOUT LEVELING SHIMS.
2.) STANDARD HEIGHT LIFT SHOWN.
LIFT CAPACITY
LIFTING SPEED (RISE TIME)
MOTOR RATING OPTIONS
WEIGHT
MECHANICAL SAFETY LOCKS
MECHANICAL SAFETY RELEASE
SWING ARM LOCKS
HYDRAULIC SAFETY SYSTEM
CYLINDERS
CARRIAGE BEARINGS
SYNCHRONIZATION
MIN. BAY SIZE
4500kg
APPROXIMATELY 54 SECONDS AT RATED
CAPACITY
SINGLE PHASE 220V 50-60Hz
3 PHASE 380V 50Hz
719kg
AUTOMATIC ALL POSITIONS
MANUAL ALL BOTH COLUMNS
AUTOMATIC LOCKING ABOVE 63.5mm
AUTOMATIC ALL POSITIONS
TWO, ONE PER COLUMN
EIGHT PER CARRIAGE, UHMW
EQUALIZATION CABLES
3657.6mm X 7315.2mm VERIFY WITH SITE PLAN
& SERVICE VEHICLES
0496-M005-0
1842mm
1928mm W/ 1727mm STROKE
100mm
165mm
3486mm
2916mm
2859mm
4000mm
4051mm
3890mm
2659mm
3352.8mm
3962.4mm
1828.8mm
