Type RPC positioner
5
Operation
5.1
Description of the operating and display elements
5
4
5.2
Control elements
► To operate the buttons and slide switches, unscrew the 4 screws (5) on the housing cover (4) and remove the housing cover (4).
The type RPC positioner is equipped with 2 buttons, 4 slide switches and 2 LEDs as display element.
NOTE!
To be able to operate the slide switches and buttons, make sure that the local operation lock is de-energized/not locked (factory
setting): with communication software.
► After setting the slide switch, fasten the housing cover of the RPC positioner again.
CAUTION!
Damage or functional failure due to ingress of dirt and moisture.
► To maintain the IP65/IP67 protection rating, screw on the housing cover with the gasket in the correct orientation.
24
5
6
No.
Designation
1
Valve
3
2
Actuator
3
Type RPC Positioner
4
Housing Cover
5
Screws
2
1
No. Designation
1
1
2
2
3
4
3
5
6
4
Taste 2
Operating Instructions
Button 1
Slide switch
Communication interface
Button 2
LED 1
LED 2
