Assembly

NOTE!
Only for positioners and process controllers without premounted process valve.
DANGER!
Risk of injury due to high pressure in the system/device.
► Before working on the system or device, switch off the pressure and vent/drain the lines.
Risk of injury from electric shock!
► Before intervening in the device or the system, switch off the power supply and secure it against being switched on again!
► Observe the applicable accident prevention and safety regulations for electrical devices!
WARNING!
Risk of injury due to improper assembly!
► Assembly may only be carried out by authorized specialist personnel using suitable tools!
Risk of injury due to unintentional switching on of the system and uncontrolled restart!
► Secure the system against unintentional operation.
► After assembly, make sure the system is restarted under controlled conditions.
4.1

Construction

5
9
10
8
7
6
No. Designation
1 Valve
2 Actuator
4
3 Assembly bridge
4 Type RPC Positioner
5 Fixing screws
6 Control air connection A1
3
7 Pressure connection P
8 Control air connection A2
9 Control air connection
2
Connection
10 Control air connection
Actuator
1
Type RPC positioner
