MAINTENANCE SPECIFICATIONS (WR426F)
Item
Clutch:
Friction plate thickness
Quantity
Clutch plate thickness
Quantity
Warp limit
Clutch spring free length
Quantity
Clutch housing thrust clearance
Clutch housing radial clearance
Clutch release method
Shifter:
Shifter type
Guide bar bending limit
Kick starter:
Type
Carburetor:
I. D. mark
Main jet
Main air jet
Jet needle-clip position
Cutaway
Pilot jet
Pilot air jet
Pilot outlet
Pilot screw (example)
Bypass
Valve seat size
Starter jet
Float height
Engine idle speed
Intake vacuum
2.9 ~ 3.1 mm (0.114 ~ 0.122 in)
9
1.1 ~ 1.3 mm (0.043 ~ 0.051 in)
8
----
48.4 mm (1.91 in)
6
0.10 ~ 0.35 mm
(0.0039 ~ 0.0138 in)
0.010 ~ 0.044 mm
(0.0004 ~ 0.0017 in)
Inner push, cam push
Cam drum and guide bar
----
Ratchet type
USA
5NG5 50
(M.J)
#165
(M.A.J)
#200
(J.N)
OBDRR-4
(C.A)
1.5
(P.J)
#42
(P.A.J)
#75
(P.O)
ø0.9
(P.S)
1-5/8
(B.P)
ø1.0
(V.S)
ø3.8
(G.S)
#65
(F.H)
8 mm (0.31 in)
1,700 ~
1,900 r/min
33.3 ~ 38.7 kPa
(250 ~ 290 mmHg,
9.84 ~ 11.42 inHg)
2 - 8
SPEC
Standard
EUROPE,
CDN, AUS, NZ,
ZA
5NG6 60
←
←
OBDQR-4
←
←
←
←
1-1/8
←
←
←
←
←
←
Limit
2.7 mm
(0.106 in)
----
----
----
0.1 mm
(0.004 in)
47.4 mm
(1.87 in)
----
----
----
----
----
0.05 mm
(0.002 in)
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
