MAINTENANCE SPECIFICATIONS (WR400F)
Item
Clutch:
Friction plate 1 thickness
Inner diameter
Quantity
Friction plate 2 thickness
Inner diameter
Quantity
Clutch plate thickness
Quantity
Warp limit
Clutch spring free length
Quantity
Clutch housing thrust clearance
Clutch housing radial clearance
Clutch release method
Shifter:
Shifter type
Guide bar bending limit
Kick starter:
Type
Carburetor:
I. D. mark
Main jet
Main air jet
Jet needle-clip position
Cutaway
Pilot jet
Pilot air jet
Pilot outlet
Pilot screw (example)
Bypass
Valve seat size
Starter jet
Float height
Engine idle speed
Intake vacuum
2.72 ~ 2.88 mm
(0.107 ~ 0.113 in)
ø112 mm (4.41 in)
7
2.92 ~ 3.08 mm
(0.115 ~ 0.121 in)
ø116 mm (4.57 in)
1
1.1 ~ 1.3 mm (0.043 ~ 0.051 in)
7
----
44 mm (1.73 in)
5
0.20 ~ 0.45 mm
(0.0079 ~ 0.0177 in)
0.010 ~ 0.044 mm
(0.0004 ~ 0.0017 in)
Inner push, cam push
Cam drum and guide bar
----
Ratchet type
5GS6 61
(M.J)
#165
(M.A.J)
#200
(J.N)
OBDRQ-4
(C.A)
1.5
(P.J)
#42
(P.A.J)
#75
(P.O)
ø0.9
(P.S)
1-1/2
(B.P)
ø1.0
(V.S)
ø3.8
(G.S)
#65
(F.H)
8 mm (0.31 in)
1,700 ~ 1,900 r/min
33.3 ~ 38.7 kPa
(250 ~ 290 mmHg, 9.84 ~ 11.42 inHg)
2 - 25
SPEC
Standard
Limit
2.52 mm
(0.099 in)
----
----
2.72 mm
(0.107 in)
----
----
----
----
0.1 mm
(0.004 in)
43 mm
(1.69 in)
----
----
----
----
----
0.05 mm
(0.002 in)
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
----
