12. Technical data

Drive unit including battery control unit
Range (1):
Speed:
Nominal gradient:
Operating voltage:
Rated power of engine:
Operating temperature:
Maximum user weight:
Protection rating:
Battery (installed in the drive unit)
Cell type:
Rated operating capacity:
Rated capacity:
Rated energy:
Charging temperature:
Operating temperature:
Weight of components
Drive:
Control unit:
Battery charger:
Total weight:
Tyre on wheel
Model and type:
Size:
Air pressure:
(*) The range varies depending on the terrain and the prevailing usage conditions. The specified maximum range is valid for optimum trav-
el conditions (level terrain, a newly charged battery, ambient temperature of 20 °C, smooth travel, etc.).
We expect an estimated average service life of five years for this product, provided that the product is used as intended and maintained
and serviced in accordance with all the instructions specified in the operating manual. This service life can be exceeded by handling,
servicing, maintaining and using the product with care and insofar as there are no technical limitations that arise from further develop-
ments in science and technology. However, the service life may also be reduced significantly by excessive or improper use. The service life
required by the applicable standards does not constitute an additional warranty.
The via GO and the corresponding off-board charger comply with the applicable sections of standard EN 12184
and ISO 7176-14 (for electrically powered wheelchairs) and comply with the EU Medical Devices Directive (MDR)
2017/745. The via GO is a class I medical device.
We reserve the right to modify the design and technology of our products to incorporate the latest developments.
Charger
For technical information and instructions, please refer to the separate operating manual for the charger.
up to 12 km (*)
1.5 km/h to 5.5 km/h in steps of 0.5 km/h
9.1° [16%] for a system weight of 170 kg
36 V
250 W
-25 °C to +50 °C
150 kg (system weight 170 kg)
IPX4
Lithium-ion cells, leak-proof and maintenance free
36 V
4.5 Ah
162 Wh
0 to +40 °C
-25 °C to +50 °C
5.3 kg
140 g
540 g
5.98 kg
Exchangeable solid rubber tyres for firm ground
123 x 45
Solid rubber wheel, therefore puncture-proof
