Limit value selectable:
Enables/ disables limit modification during power on sequence.
Selectable Mode:
Enables/ disables mode selection during power on sequence.
Measurement output (requires the optional analog interface):
Enables/ disables output and defines force range.
1.1.1 Operating bars
The menu bar and the tool bar may be customized by the user. The procedure is:
Move the mouse into the area of menu/ tool bar
Click the right hand sided mouse key (context menu)
The menu displayed allows activation/ deactivation of the menu bar, tool bar and state bar.
Additionally, the graphic view may be defined.
More settings are available by selecting "Customize".
Operating bars (tool bar):
Activating/ deactivating the entire tool bar. It is also possible to reset the tool bar to a default
state.
Actions:
Individual setting of the tool bar.
