DISPLAY UNIT SEB2 / SEB2.2

The display unit is used to display, evaluate and store the measurements. A short guide to
measure is attached to the back of the display unit.
The functions of the display unit are:
Controlling measurements
Storing measurements
Display measured peak force and evaluate measurements
Upload measured data to a PC
3.1

DISPLAY, OPERATING ELEMENTS

The display unit elements are three LEDs and a 3.5 digits LCD display.
The meanings of the LEDs are:
! State LED

Result LED: not OK
 Result LED: OK
There is one button to operate the display unit:
 Operating button
