4.2.2.1.6.7. Temperature inputs 2
This example shows the structure of an auto-TX package with the
settings for PT-100 channel 1 and 2.
CAN-Data- Bit
Byte
1 0-7 Value channel 1 (Bit 0-7)
2 0-6 Value channel 1 (Bit 8-14)
7
3 0-1 Factor channel 1 (
2-7 not used
4 0
1-7 not used
5 0-7 Value Channel 2 (Bit 0-7)
6 0-6 Value Channel 2 (Bit 8-14)
7
7 0-1 Factor channel 2 (
2-7 not used
8 0
Content
Sign channel 1 (0 = positiv, 1 = negativ)
0 [dez] = illegal value / Sensor not
connected,
1 [dez] = Factor 10,
2 [dez] = Factor 100)
Status PT100 Sensor channel 1
(0 = not connected, 1 = connected)
Sign channel 2 (0 = positive, 1 =
negative)
0 [dez] = illegal value / sensor not
connected,
1 [dec] = factor 10,
2 [dec] = factor 100)
Status PT100 Sensor channel 2
(0 = not connected, 1 = connected)
