6. Sets which
counter mode
be used. There are 5 different modes available. A detailed
description of the modes can be found in the manual "RO-
CNT8".
7. Depending on the mode selected under 6., the corresponding
submodels are available. A detailed description of the
submodules can be found in the manual "RO-CNT8".
8. Sets the filter how long a signal must be at least to be recognized
as high. It can be selected from 16 predefined filters between
20ns and 5ms (only for RO-CNT8 modules).
9. Press
"Apply"
(only for RO-CNT8 modules) should
to accept the changes.
