4.2.3.6.5. Digital input-counter (48-Bit) - 64-Bit package
Configuration of an 8-byte CAN package:

CAN-Data-Byte Bit

1 0-7
2 0-7
3 0-7
4 0-7
5 0-7
6 0-7
7 0-3
7 4-7
8 0
8 1-3
8 4-7
Content

CNT8 counter 1 (Bit 0-7)

CNT8 counter 1 (Bit 8-15)

CNT8 counter 1 (Bit 16-23)

CNT8 counter 1 (Bit 24-31)

CNT8 counter 1 (Bit 31-39)

CNT8 counter 1 (Bit 40-47)

CNT8 counter 1 Counter mode
CNT8 counter 1 Sub mode
CNT8 counter 1 Input state
(0/1)
Not used
CNT8 counter 1 Input filter
