4.2.3. CAN Configuration Utility

Note:
To configure a CAN-Module, you have to enable the Software-
Mode.
Configuration products of the RO-Series
Configuration products of the BS-Series
The CAN configuration utility allows easy configuration of products
with a CAN interface. It is possible to transfer and read
configurations on modules.
In addition, auto-receive mode (Auto-RX) and auto-send mode
(auto-TX) can be configured.
The Auto-TX mode allows cyclic transmission of data packets,
alternatively with analog or digital input states to other CAN
addresses.
Alternatively, a trigger event can also be defined. In this case, a data
packet is not transmitted until a data packet has previously been
received on a certain CAN ID
(for example, CAN sync on ID 0x80).
With the Auto-RX mode, received data packets are forwarded
directly to analog or digital outputs. For example, relay outputs can
be set via another CAN bus subscriber.
The following settings can be changed:
Baudrate
Address-mode
Module-ID
Response-ID
Start modes for submodules
Automatic transmit mode (TX-Mode)
Automatic reception mode (RX-Mode)
