2. Hardware Description
The bit pattern generator offers the opportunity to output a given bit
pattern with a simple source code software. The bit pattern width is
36 bit and is able to be output by a speed up to max 200MHz to all
36 channels. In Addition, the software offers to program an arbitrary
repetitive sequence to repeat bit pattern sequences.
2.1. Bit Pattern Generator
Power supply via USB-Port (max. 500mA)
36 channels
36 Bit bit pattern width
Sample Puffer: 512 Kbit / channel
Repeat count: free configurable 1..65535 / unending
Connector: 2x 20pol connector (contact spacing 2.0 mm)
Dimensions: 117x79x24 (LxBxH in mm)
Temperature range: 0°C until +50°C
