4.2.3.6.6. Analog in- / outputs

4.2.3.6.6.1. Analog inputs

Configuration of an 8-byte CAN package:
CAN-Data-Byte Content
1
2
3
4
5
6
7
8
The value range of an A / D converter indicates in which range
analog signals (for example in the range 0-5V) are converted
digitally. The settings for the value range can be made in the CAN
configuration utility.
Note:
The hexadecimal value FFFF always indicates the upper limit of a
value range, the value 0000 the lower value.
Formula (A / D mode +/- 10V, +/- 5V or + / 2.5V)
Voltage = (value * (maximum voltage value * 2) / 0xFFFF) - max.
A/D channel 5 (Bit 0-7)
A/D channel 5 (Bit 8-
15)
A/D channel 6 (Bit 0-7)
A/D channel 6 (Bit 8-
15)
A/D channel 7 (Bit 0-7)
A/D channel 7 (Bit 8-
15)
A/D channel 8 (Bit 0-7)
A/D channel 8 (Bit 8-
15)
