Construction Of The Model Aircraft; Removing And Installing The Canopy - Reely Mini Hawk Bedienungsanleitung

The LiPo flight battery can also be charged with another matching LiPo charger. However, it must have a balancer for
monitoring and, if necessary, adjustment of voltages of individual cells.
Observe the operating instructions for the LiPo charger used. If in doubt, only use the included charger.
Warning!
Only use a matching LiPo charger to charge the LiPo flight battery. Never attempt to charge the LiPo flight
battery with a different or non-matching charger! This may cause a fire or explosion! Only charge the flight
battery when you are able to monitor the charging process.

9. Construction of the model aircraft

Before starting with the assembly of the model, prepare an appropriate surface.
In order to achieve excellent flight performance, your model is manufactured with a light plastic foam. However, this
material has a sensitive surface. Even minor carelessness during assembly and later during operation of the model
may very quickly result in ugly dents, scratches or other surface damage.
Therefore, proceed carefully.
a) Removing and installing the canopy
The canopy is held in place with a pin at the front and a magnet at the back.
To remove the canopy, lift it at the back and pull it up and away.
To put the canopy on, first guide the canopy pin under the fuselage at the front and then place the canopy onto the
magnet at the back.
53
