English
To change the equalizer settings do the following:
To enter the menu, press the "M" button.
1
Use the " " or " " button to navigate into the menu Speaker Setup [SPS] and press the "OK" button to confirm.
2
Select the menu Speaker EQ (Equalizer) and confirm with the "OK" button.
3
Use the "+" or "–" button to select desired loudspeakers and change the EQ using the "+" or "–" button.
4
• EQ1 for installation on top of an open shelf resp. cupboard (factory setting).
• EQ2 for an installation on top of a closed shelf resp. cupboard.
• EQ3 in case of the Soundbar 10 mounted to a wall.
Press the "M" button to exit this menu item.
5

Xover Small Speakers [XOV]

With this menu item you can set the crossover frequency between a (connected) Canton Smart small or bookshelf speaker and the internal
subwoofer resp. a connected subwoofer. This function is only available if at least one Canton Smart small or bookshelf speaker is connected
wirelessly, otherwise this function is grayed out. Multiple crossover frequencies are available between 40Hz and 200Hz. In general: The smaller a
speaker, the higher the crossover frequency.
To set the crossover frequency between speaker(s) and the subwoofer please do as follows:
Press the "M" button on the remote to enter the menu.
1
Confirm the first menu item Speaker Setup [SPS] by pressing the "OK" button.
2
Use the " " or " " button to select the menu item Xover Small Speakers [XOV] and confirm with the "OK" button.
3
Choose the desired crossover frequency using the "+" or "–" button.
4
Press the "M" button to confirm your selection and to exit this menu item.
5

Subwoofer Setup [SUB]

In this menu you can adjust the phase of a connected subwoofer and activate different Sub Stereo Modes [SSM] and adjust the crossover frequency
between a subwoofer and the (connected) front speakers. This menu item is only available if a Canton Smart subwoofer is connected or if the Sub
Out [OUT] is activated in the System Setup [SYS].

Sub Phase [PHA]

Use this function Sub Phase to change the phase of a connected subwoofer between 0 degree (factory setting) and 180 degree (phase inverted)
relative to the other speakers. Try a phase shift of 180 degree in case the bass level at the selected crossover frequency in the menu Xover Small
Speakers [XOV] seems to be much too low or completely off. This function works for both, wirelessly and wired subwoofers. This function is only
available if a Canton Smart subwoofer is connected or if the Sub Out [OUT] is activated in the System Setup [SYS].
90
