Refrigerant Piping - Hitachi RCIM UNIT Installationsanleitung

Suspension bolts (4)
Suspension Bracket
NOTE:
If a false ceiling has already been installed, complete all
-
piping and wiring work inside the ceiling before hooking-
up the indoor unit.
Secure the indoor unit using the nuts and flat washers.
-
Space Adjusting Between Indoor Units and
False Ceiling Opening
Check the level of the drain pan by a water level to avoid
-
incorrect operation of the drain discharge mechanism in
the indoor unit.
Tighten the nuts of the suspension brackets after the
-
adjustment is completed. Apply LOCK-TIGHT paint to the
bolts and nuts in order to prevent them from loosening. If
not done, abnormal noises or sounds may occur and the
indoor unit may come loose.

3 REFRIGERANT PIPING

3.1. PIPING CONNECTION
3.1.1. PIPING POSITION
Piping connection position is the following, which is
available from all directions, top, left or right.
Gas Piping
Liquid Piping
3.1.2. PIPING CONNECTION SIZE
Piping size
Model RCIM 1.0/1.5
Gas Piping 12.70 (1/2)
Liquid Piping 6.35 (1/4)
