Fusion process
When the fusion operations are going to finish, an acoustic signal alerts the user that the
process is near to complete.
As soon as the fusion process is correctly ended the display shows briefly the information
concerning the real fusion time and the total energy applied to the jointing. These data will
be part of the welding protocol stored into the internal memory.
2.12.2

Cooling time

After the completion of the fusion process, the protocol summary and the remaining
cooling time, if contained in the barcode, are displayed alternately. Messages are active
till the user will press the STOP/ESC (O) button or will detach the fusion cables from the
fitting, to proceed with the next welding.
At the end of the fusion cycle the user has to wait till the cooling time expiration, before
applying pressure to the fitting! Remove the external clamp only when the cooling time is
expired!
Danger of burning! The fitting area is hot! Pay attention during the removal of the cables.
When the cooling time is going to finish, an acoustic signal alerts the user the process is
near to complete.
STOP/ESC (O), and the cooling time is expired, a message concerning the time expiration is
shown.
FUSION DONE
+GF+ C 320 mm
t= 300 s E=152,8KJ
FUSION DONE. DETACH THE CABLE TO
MOVE TO NEXT WELDINF. FUSION 19/5000
COOLING TIME
10'
FUSION DONE,COOLING TIME IN PROGRESS
WAITT TILL THE END OR DETACH THE CABLE
If the
COOLING TIME
0'
COOLING TIME IN PROGRESS. DETACH THE
CABLE TO PROCEED NEXT WELDING
Operating manual MSA 4
22°C
09:21 11.03.14
22°C
09:21 11.03.14
operator does
22°C
09:21 11.03.14
not push
