Selecting the Record Rates
D4 continuously records to its internal hard disk. The amount of time the hard disk will record for depends on a number of factors:
• Hard disk capacity (disk size in Gigabytes).
• Image quality (file size in Kilobytes).
• Record rate (pictures per second).
The tables below shows the recording rates for different image quality and hard disk sizes.
40GB
Record
24 hours
duration
LOW MED HI
Quality
14K 18K 25K
40GB
17PPS 17PPS 17PPS
160GB
Record 24 hours
duration
LOW MED HI
Quality
14K 18K 25K
160GB
17PPS 17PPS 17PPS
Using the Table:
1. Select the internal hard disk size on the left.
2. Select the number of hours to record across the top.
3. Select the image quality (LOW, MED, or HIGH).
4. Read down the table for the record rate in pictures per second (PPS).
An interactive record rate calculator is available on our website at www.dedicatedmicros.com
26
48 hours 72 hours
LOW MED HI LOW MED
14K 18K 25K 14K 18K
15PPS 12PPS 8PPS 10PPS 8PPS
48 hours 72 hours
LOW MED HI LOW MED
14K 18K 25K 14K 18K
17PPS 17PPS 17PPS 17PPS 17PPS
168 hours
(7 days)
HI LOW MED HI LOW
25K 14K 18K 25K 14K
5PPS 4PPS 3PPS 2PPS 2PPS
168 hours
(7 days)
HI LOW MED HI LOW
25K 14K 18K 25K 14K
17PPS 17PPS 14PPS 10PPS 9PPS
336 hours 744 hours
(14 days) (31 days)
MED HI LOW MED HI
18K 25K 14K 18K 25K
1PPS 1PPS 1PPS -
336 hours 744 hours
(14 days) (31 days)
MED HI LOW MED HI
18K 25K 14K 18K 25K
7PPS 5PPS 4PPS 3PPS 2PPS
-
