Activity Camera Setup

Detection
Activity Camera Set-up
Sensitivity
Activty grid
Activity test
Activity detection is used to record more images to disk from cameras that
have activity. The sensitivity of activity can be adjusted and areas can be
masked off according to the scene type.
Detection
Select whether activity detection is on or off for the selected camera.
Sensitivity
There are 5 levels of sensitivity for activity detection.
Select the sensitivity level which matches the camera's placing. Cameras sited
outdoors where there may be a lot of background movement, such as trees or
rain, should be set to Outdoor high, Outdoor low or very low sensitivity.
Cameras sited indoors where there is very little background movement should
be set to Indoor high or Indoor low sensitivity.
Activity Grid
An 8 x 16 grid is used to mask areas where activity detection is enabled. When
the grid is displayed, use the cursor keys to move the cursor to the desired
location and press a camera key to toggle the block on (white dot) or off.
Activity Test
Use this option to test and tune the sensitivity and activity grid set up for each
camera. When activity is detected on the camera a white dot is displayed.
Press the mode/menu key to exit the test.
24
On
Off
Outdoor low, Very low, Indoor high, Indoor low
Outdoor high
Setup
Walk test

Activity Search

It is possible to search an area of the screen for activity or text at specified
times.
To Search for Activity or Text:
1. Enter playback mode by tapping either
GOTO key.
2. Press and hold the Event key to display the Search Setup menu:
Search Setup
Camera 1
Define
Copy destination
Activity From
Activity To
Playback time
Camera
This is the camera number you will be performing the search on, press a
camera key to change to the relevant camera number.
Define
This option defines the area of the screen you need to search. Follow the on-
screen instructions to select an area of the screen to search for activity.
Copy Destination
This is the device you wish to copy selected images to, select External to copy
to Zip/Jaz, or CDR List to copy to the CDR Archive page.
Note: The External option is available for backward compatibility where ZIP or
Jaz are in use.
, , or pressing and holding the
Activity Setup
CDR List
13:25 19/03/2003
12:00 01/01/2002
