CD
The D4 CD operates in the same way as the D4 and offers a built in CD writer
supporting simple and easy storage of images recorded to the hard drive of the
unit. The CD writer is accessible from the front of the unit.
The operation of the internal CDR is identical to using the external CDR as
described on the D4 Setup Guide.
EVENT COPY
1 2 3 4
LIVE PLAY SPOT
To Insert a CDR:
1. Press the button on the CDR drawer.
2. Pull the CD drawer out until there is resistance
3. Place the CDR with the writing side up on the spindle and press down until
there is a click.
4. Push the drawer back in until it latches.
To Remove a CDR:
1. Press the button on the CDR drawer.
2. Pull the CD drawer out until there is resistance.
3. Hold the CDR between thumb and forefinger and lift to remove from the
spindle.
4. Push the drawer back in until it latches.
Note: In the event of a CD becoming jammed in the drive, or a power failure, it
is possible to open the CDR drawer by inserting a thin object such as a paper
clip, or watchmaker's screwdriver into the small hole in the CDR drawer and
applying pressure until the drawer unlocks.
MODE MENU
GOTO
RECORD
WARNING: The CDR is a Class 1 laser product to EN 60825-1:1994, avoid
exposure to the beam.
Selecting CD-Rs and CD-RWs
The internal CD writer in the D4 CDR is not compatible with Ultra Speed
CDR's. Ensure that only High Speed or Multi-Speed CDR media is used. This
is normally written on the CDR packaging and on the disk itself.
