Connecting to an Ethernet network

D4 can be connected to a standard 10-baseT Ethernet network allowing full
control of the D4 from a remote location.
Network Connection
To connect a D4 to a network you will need the following items:
• A spare 10-baseT network point.
• A RJ-45 network cable (CAT5 or equivalent).
• A static IP address and Subnet mask (some networks may also require a
Default gateway; consult the network administrator for advice).
To configure the D4 on the network you will need to perform the following
steps:
1. Enter the D4 menu (press and hold the Menu button).
2. Tap the Menu button until the 'System Options' page is displayed.
3. Use the cursors to select Network Settings.
4. Enter the Network settings menu by highlighting Edit and pressing the up or
down cursor.
5. Enter the IP address, Subnet mask and Default gateway in the spaces.
Note: The addresses are four sets of three digits, if you have only two digits
in the address insert a 0 before the number i.e. 123.123.123.001
6. Press the Menu button to exit the menu.
7. Press Camera 1 to accept the changes and reboot the system, or press
Menu again to exit without changing the settings.

Viewing Images Across the Network

D4 can use either a web browser or Network Viewing Software to view images
across the network. The Network Viewing Software can be downloaded from
the unit onto your local PC using the network connection.
To download the Network Viewing Software:
1. Open your web browser software on your PC.
2. Enter the IP address of the D4 in the 'Address' box in Internet Explorer or
Netscape and press Enter.
Note: Remove all preceding 0's, i.e. 123.123.123.001in the D4 should be
entered as 123.123.123.1 in the web browser.
3. A web page from the D4 is loaded. Click on the PC viewer application
icon, you will be prompted to Save or Run the program.
4. Select Run this application from its current location.
5. The software will download and install, follow onscreen prompts.
6. The program can be found in Start > Programs > DM Network Viewer.
Details of using the Network Viewing Software can be found in the User Guide
in the Network Viewing Software folder.
The minimum specification PC for viewing images over a network is:
• 500 MHz CPU.
• 64MB RAM.
• 4MB video card (capable of 16 million colours).
• Minimum of 800 x 600 screen resolution.
9
