Operating

Playing Back Images from the Disk
Playback
1. To playback images tap to rewind to the desired location and then press
2. When in playback, tap or to search rewind or fast forward, multiple taps will increase the
search speed.
II
3. Tap to pause the current image. Tapping
frame.
4. Press to return to Play mode.
Goto time
1. Press and hold (GOTO) to play back from a specific time or date.
2. Enter the required time and date using the cursor keys, and press
Tip: The images are updated in the background automatically when the time and date is adjusted.
Exit playback
1. Tap the MODE key to exit Playback mode. The Play LED will be Off.
Using the Event Log
Alarms and activity detection are tagged and stored in the event log for easy retrieval. Each event is
labelled with event type (alarm, activity, system), its camera title, time, and date. To view an event from
the event log:
1. In Live mode with control of the Main Monitor tap EVENT to display the event log.
2. Use and to select the event required, the selected event is displayed in the preview window.
3. Tap to view the event in full screen.
4. Tap MODE to exit the Event log.
Event Search Filter
It is possible to filter the search by selecting a particular function (alarm, activity or system) within the
time and date and on a specific camera. To enter this option, with the Event log displayed press the
EVENT key again. This will display the Event Search Filter menu.
Tip: You can enter this menu by holding down the EVENT key.
.
or whilst paused will advance or rewind the
.
Viewing Single Cameras
Full
Pressing a camera key will display a full screen image of that camera.
Zooming an image
Press the same camera key to toggle zoom on and off.
When zoom is enabled, use
Note: Zoom is not available in playback mode.
Freezing an image
Double tap the camera key to toggle freeze frame on or off.
Viewing Multiple Cameras
Picture in Picture
Press the PIP key to toggle the main and PIP image.
Press and hold the PIP key to edit the display, use
the required camera key to fill that segment.
Press MENU to exit.
Quad
Press the QUAD key to switch to quad display.
Press and hold the QUAD key to edit the display, use
press the required camera key to fill that segment.
Press MENU to exit.
Sequencing Cameras
Sequence
Press the SEQUENCE key to toggle the main monitor sequence on or off.
Press and hold the SEQUENCE key to edit the full screen sequence.
Use the camera keys to include or remove cameras from the sequence.
Press MENU to exit.
Note: The spot monitor sequence can only be activated or edited in spot mode.
to scroll around the image.
to select the segment, press
to select the segment,
