Camera Setup

Title
Camera Set-up
Input termination
Camera type
Alarm input/Polarity
Telemetry protocol
Colour adjust
Contrast adjust
Camera video input
Title
Each camera title can be up to 12 characters long.
Input Termination
The input termination does not auto detect by default, the termination must be
set manually On (default) or Off. The termination must be set to Off if the
camera is looped through to other equipment.
Camera Type
Colour and monochrome cameras are detected automatically, allowing
colour/mono switching cameras to be connected. The camera type can be
manually configured as Colour or Mono if necessary.
Alarm Input/Polarity
Select whether the alarm connected is Normally open (default), Normally
closed, or Off.
Telemetry Type
Once the type of telemetry has been selected in the 'System Options menu'
(see above), the telemetry has to be allocated to a particular camera input.
Note: It is necessary to allocate an input and enable this within this option for
the system to operate correctly.
CAMERA 1
Off, On
Auto detect
Colour, Mono
Auto detect
Normally closed, Off
Normally open
None
--------|-------
--------|-------
Disconnected
Connected
Colour Adjust
When the colour bar is selected, press
colour.
Note: this option is not displayed if the camera is set as monochrome.
Contrast Adjust
When the contrast bar is selected, press
contrast.
Camera Video Input
This option is only displayed when a camera has failed or is offline. Select
disconnect whilst the camera is offline to prevent the camera fail message
and alarm being triggered.
Tip: This menu can be entered directly by pressing and holding a camera
key.
to reduce, and to increase the
to reduce, and to increase the
