Console
MDI
Fehlermeldung
Fehler-
H0, H1DN,
Code
H2, H3
50
LEFT I=0 EVER
51
RIGHT I=0 EVER
52
PUMP I=0 EVER
53
STBY I HIGH
54
LEFT STBY I HIGH
55
RGT STBY I HIGH
56
PUMP STBY I HIGH
57
HIGH FIELD CUR
58
NO FIELD CURRENT
59
HIGH BRAKING I
60
CAPACITOR CHARGE
61
HIGH TEMPERATURE
62
TH PROTECTION
63
THERMIC LEVEL #2
64
PUMP TEMPERATUR
65
MOTOR TEMPERAT
66
BATTERY LOW
67
BATTERY LEVEL #2
68
BATTERY LEVEL #1
69
CURRENT SENS KO
70
HIGH CURRENT
71
POWER FAILURE #3
72
POWER FAILURE #2
73
POWER FAILURE #1
74
DRIVER SHORTED
75
CONTACTOR DRIVER
76
COIL SHORTED
77
COIL INTERRUPTED
78
VACC NOT OK
79
INCORRECT START
80
FORW + BACKW
81
BAD STEER 0-SET
82
ENCODER ERROR
83
BAD ENCODER SIGN
84
STEER SENSOR KO
85
STEER HAZARD
86
PEDAL WIRE KO
87
PEDAL FAILURE
88
TRACTION BRUSHES
89
PUMP BRUSHES
90
DRIVER 1 KO
91
DRIVER 2 KO
92
DRIVER 1 SIC KO
93
DRIVER 2 SIC KO
94
INPUT ERROR #6
95
INPUT ERROR #5
96
INVERTION
97
POSITION HANDLE
98
INPUT ERROR #2
99
INPUT ERROR #1
124 / 129
Anhang MDI
Abweichungen bei anderen Steuerungen
Console
Fehlermeldung
Fehlermeldung
SEM 2/3
SEM 0/1
Combi SEM
SERIAL ERROR
(bis Vers. 0.06)
PUMP VACC NOT OK
HANDBRAKE
INPUT ERROR 2
INPUT ERROR 1
CLEARING MDI HM
CLEARING MDI HM
CHECK UP NEEDED
CHECK UP NEEDED
ADWZP0DF
Console
Console
Fehlermeldung
Dual SEM
R FIELD I LOW
L FIELD I LOW
R FIELD I HIGH
L FIELD I HIGH
MICRO CHECK KO
OPERATOR ABSENT
BRAKE DRIVER KO
HANDBRAKE
CLEARING MDI HM
CHECK UP NEEDED
Console
Fehlermeldung
AC-Serie
PROG LIFT LEVER
CAN BUS KO
SAFETY
ENCODER ERROR
HANDBRAKE
ENCODER TEMP
THERMIC SENS KO
PEV NOT OK
WRONG SET BATT
DATA ACQUISITION
MASTER KO
CLEARING MDI HM
CHECK UP NEEDED
AC-3 FLASH / AC-4 FLASH
