• Please read this document carefully before using the product.
• Follow the safety instructions to avoid injuries and damage to the product.
• Instruct the user in the proper and safe use of the product.
• Please keep this document in a safe place.
1 Components (Fig. 1)
1.1 Single components
(for 3R36 in brackets)
(1) 4G60 (4G111) Upper Joint Section
(2) 4G61 (4G112) Lower Joint Section
(3) 4G117 Plastic Knee Cap
(4) 501Z2=M4x12 Cap Screw with
Hexagon Socket
(5) 4H58 Extension Stop, complete
(6) 4G62=N (4G114=N) Posterior Linkage Bar
(7) 4Z40 Stop Bumper
(8) 4G53 (4G113=N) Anterior Linkage Bar
(9) 501T15=M6x40 Cap Screw with
Hexagon Socket
(10) 4B86 Knee Axis Bushing
(11) 4V99 Pin for Extension Assist
(12) 513D34 Spring for Extension Assist
1.2 Single-Component Packs (Fig. 1, ●)
4D13 Single-Component Pack for 3R20 and 3R36
Consisting of: 1 Plastic Knee Cap, 1 Cap Screw, 1 Extension Stop, complete,
1 Stop Bumper, 1 Pin for Extension Assist, 1 Spring for Extension Assist,
1 Adjustment Screw, 1 Bearing Ball, 2 Lock Nuts, 2 Posterior Axis Pins, 4 Brass Washers,
4 Washers.
2 Description
2.1 Indications for use
The Ottobock Habermann Modular Knee Joints 3R20 (stainless steel) and 3R36 (titanium) are to
be used exclusively for the prosthetic fitting of amputations of the lower limb.
2.2 Field of application
Field of application according to the Ottobock Mobility System MOBIS:
Recommendation for mobility grades 1 and 2 (indoor walkers, restricted out-
door walkers). Approved for patients with a weight of up to 100 kg/220 lbs.
3R20, 3R36
(12a) 513D34=L Spring for Extension Assist
(13) 4Z41 Adjustment Screw
(14) 4V100 Spring Housing
(15) 509Y1=8.0 Bearing Ball, stainless steel
(16) 506G3=M6x6 Set Screw with Hexagon
Socket
(17) 4B90=12-K Bushing
(18) 502S19=M6 Lock Nut
(19) 4A50 Posterior Axis Pin
(20) 4Z49=20 Brass Washer
(21) 4B91 Friction Stop Bumper
(22) 507U16=6.4 Washer
(23) 709S18 Wrench
