Remote Control Settings; Prosthesis Administration - Ottobock Genium Gebrauchsanweisung

Remote Control Remote Control
7.9 Remote Control Settings
INFORMATION
Advise your patient of the information in this section.
1. In the main menu, use
2. Adjust the date and time by selecting the corresponding line. Change settings using the navigation keys.
3. Additional connections can be established ("PAIRING"). Connections can be deleted ("DELETE CONNECTION")
(see Section 7.10 "Prosthesis administration").
4. The font size in the menu bar can be changed by selecting "ZOOM".
5. - 6. On the screen, use
confirm.
7. Information about the firmware version of the knee joint and signal strength is accessible under "Info". Select the
arrow symbol to return to the main menu on the display.
7.10 Prosthesis Administration
Connections with up to four different prostheses can be stored in a single remote control. Conversely, a prosthesis
can only be connected to a single remote control. Complete the following steps to add additional connections:
1. In the main menu, use
2. Select "PAIRING" from the menu that appears.
3. The remote control searches for other prostheses in range.
58 | Ottobock 58 | Ottobock
to select „RC SETTINGS" (remote control settings) and press the enter key to confirm.
to select the normal (1, ) or large font size (2, ) and then press the enter key to
to select „RC SETTINGS" (remote control settings) and press the enter key to confirm.
Genium - Bionic Prosthetic System Genium - Bionic Prosthetic System
