Packaging and unpackaging
The machine is packaged in cardboard with polystyrene inserts
to guarantee full integrity during transport.
•
Handle the packaging according to the instructions.
•
Open the packaging and check the integrity of all
components. Keep packaging for future moves.
•
Lift the machine as indicated and place it in the installation
area.

Installation area

The arranged area must be suitably illuminated and an electrical socket must be available. The resting
surface must be sufficiently ample, even and dry. The machine must be installed in rooms with non-explosive
environments. In any case, installation must also be performed in consideration of the work safety laws in
force.
During installation operations it is best to observe the minimum measurements found in fig. 4 and 5, having
care to remove the protective film placed on the painted housing.
Room conditions table
Descriptions
Working temperature
Storage temperature
Relative humidity
Dustiness
0÷35 °C (32÷95 °F)
-15 to +65 °C (from –6.8 to +149 °F)
Maximum 80% with 20 °C room temperature
Maximum 50% with room temperature between 20÷60 °C
Less than 0.03 g/m³
8
INSTALLATION
INFORMATION
Values
2
