5. Moving the crosshair on
the profile:
- Start from Step 1 to
set or select a profile
analysis.
- Press the 3LEFT,
RIGHT4arrow (for
horizontal profile) / UP
file) arrow on the omni selector to move the crosshair
on the profile.
Isotherm analysis
1. Press the MENU/EN-
TER key.
2. Press the 3LEFT or
RIGHT 4 arrow on the
omni selector to select
the [Analysis] menu.
3 . Press UP and DOWN
s
arrow to select [Iso-
t
therm], then press the
Menu/Enter key. Areas
of concern will be high-
lighted with color.
4. Setting isotherm range:
- Start from Step 1 to
set or select iso-
therm analysis.
- [Isot] message will
appear in the opera-
tion indicator.
- Press the UP
s
DOWN arrow on
t
the omni selector to
select isotherm range.
- IL and IH will ap-pear
at the bottom right corner. It is the high limit (IH)
and low limit (IL) of the isotherm range.
B - 17
, DOWN (for vertical pro-
s t
or
Operating manual – Infrared camera
Remove analysis tools individually
1. Press the MENU/ENTER key.
2. Press the 3LEFT or
RIGHT4 arrow on the
omni selector to select the
[Analysis] menu.
- Current analysis tool
will appear in the
operation indicator .
- You can skip this step and step 3 when the analysis
tool you want to remove is the current analysis tool.
3 . Select the analysis tool you want to remove.
4. Press the C key to remove it.
Remove all analysis tools
1. Press the MENU/EN-
TER key.
2. Press the 3LEFT or
RIGHT 4 arrow on the
omni selector to select
the [Analysis] menu.
3 . Press UP and DOWN
s
arrow to select [Re-
t
move all], then press
the Menu/Enter key. All
analysis tools removed.

Saving the Image

You can save the image in the menu system after you
freeze an image, or save it directly by holding the S key
on the omni selector for 3 seconds when the camera is
in Null mode without freezing an image.
1. Press the MENU/EN-
TER key.
2. Press the 3LEFT or
Right4arrow on the
omni selector to select
the [File] menu.
