3 . Press UP and DOWN
s
arrow on the omni
t
selector to select [Com-
ment], then press the
Menu/Enter key.
- The [Comment] window
will appear on the
LCD monitor (or in the
viewfinder).
4. Select a comment by
pressing the UP
s
DOWN arrow on the
t
omni selector, and then
press the Menu/Enter key to attach a text comment.
5. Save the image.

06. PlaYBacK anD erase

Opening Images

You can view and analyze
the recorded images on
the LCD monitor (or in the
viewfinder).
1. Press the MENU/EN-
TER key.
2. Press the 3LEFT or
RIGHT4 arrow on the
omni selector to select
the [File] menu.
3. Press UP and DOWN
s
arrow on the omni
t
selector to select [Open],
then press the Menu/
Enter key.
4. Select an image, then
press MENU/ENTER key
to open it. You can ana-
lyze and attach memo
to a recorded image
when you open it.
B - 19
or
Operating manual – Infrared camera
How to select an image
1. After you select [Open] or [Delete] option under
[File] menu, a message shown as below will ap-
pear in the lower left of the screen.
69141330.SAT 001
2006-10-12
File name of the The date on
current image which the
current image
was saved
2. If the image you wish to open or delete is not in
the current folder, press the UP
.. <DIR>
Enter or Cancel
omni selector until the following message appear:
3. Press [Menu/Enter] key to select a dirtory or
press [Cancel] key to exit. After you press
20061012 <DIR>
001 / 002 / 003
[Menu/Enter] key to select a directory, a message
Folder name of Numbers of
appear on the screen.
the current folder images in the
current folder.
4. Press UP or DOWN
s
to select a folder, then repeat step 1 to select an image
in the selected folder.
010
Number of Sequence
number of the
Images in this
current image
folder
, arrow on the
s
Sequence Numbers of
numbers of the folder in the CF
folder
] arrow on the omni selector
t
Card
