Critical faults may only be corrected by persons trained in the
system servicing tasks.
If multiple errors are present, these are displayed one after anoth-
er.
You can switch between the displays using the arrow keys.
Malfunction
Malfunctions are errors occurring during the washing program.
The washing program is interrupted and can be resumed after
elimination of the malfunction.
If multiple malfunctions are present, these are displayed one after
another.
You can switch between the displays using the arrow keys.
A detailed description of troubleshooting is provided in chapter
Troubleshooting guide.
An event is an error occurring when no washing program is ac-
tive.
If multiple events are present, these are displayed one after an-
other.
You can switch between the displays using the arrow keys.
A detailed description of troubleshooting is provided in chapter
Troubleshooting guide.
System not in initial position
This message appears when one or more power units are not in
their respective initial position.
Note
Event
Press and hold the button (> 2 seconds) or press and hold the
blue button (> 2 seconds) to move the system to the initial posi-
tion.
This message appears when a service date is due.
Note
Contact the Service to arrange a servicing appointment.
1. Open the stop valves for water and compressed air.
2. Set the main switch at the main supply distributor to "1".
3. Press the blue control voltage/initial position button on the
control panel.
System ready for operation. The vehicle to be washed can now
be driven in.
DANGER
Danger from moving system components
Switch the system off immediately using the emergency off but-
ton in the case of danger to persons, property or animals.
ATTENTION
Risk of damage to the vehicles through inadequately re-
moved cleaning agent
If a malfunction occurs in the washing bay after application of the
cleaning agent, you must remove the cleaning agents by spray-
ing thoroughly with water after switching off the system to prevent
paint damage due to an excessively long cleaning agent expo-
sure time.
Note
In self-service systems, a person must always be available during
operating periods who is familiar with the washing system and
can take or initiate the measures necessary for preventing poten-
tial dangers.

Switching on again after an emergency off

Note
Correct the reason for actuating the emergency off button before
switching the system on again.
Persons or animals must not be present in the work area. Any ve-
hicles present must be driven out of the system.
English
Service required

Start-up

Operation
