Spezifikationen
X1 Mains 50 mm
X2 Drive 50 mm
X3/X4 Capacitor disconnect 16 mm
A/B Temperature 2.5 mm
F1
F2
PE M8
210.5 ±1 mm [8.3 ±0.04 in]
63.8 ±2.5 mm [2.5 ±0.1 in]
9.0 ±1 mm [0.4 ±0.04 in]
Abbildung 7.35 IP20 X5 Externer Lüfter 2
Abbildung 7.36 IP20 X5 Externer Lüfter 2, 3D-Ansicht
MG80C503
Projektierungshandbuch
2
2
2
2
597.0 ±2.5 mm [23.5 ±0.1 in]
240.0 ±1 mm [9.4 ±0.04 in]
9.0 ±1 mm [0.4 ±0.04 in]
685.0 ±2.5 mm [27.0 ±0.1 in]
775.3 ±2.5 mm [30.5 ±0.1 in]
Danfoss A/S © 10/2016 Alle Rechte vorbehalten.
370.0 ±2.5 mm [14.6 ±0.1 in]
418.0 ±2.5 mm [16.5 ±0.1 in]
210.5 ±1 mm [8.3 ±0.04 in]
50.5 ±2.5 mm [2.0 ±0.1 in]
7
7
79
