Danfoss VLT AHF 010 Projektierungshandbuch Seite 112

Spezifikationen
242.8 ±2.5 mm [9.6 ±0.1 in]
7 7
9.0 ± 1.0 mm [0.4 ± 0.04 in]
Abbildung 7.97 IP21 X6 Externer Lüfter 1
Abbildung 7.98 IP21 X6 Externer Lüfter 1, 3D-Ansicht
110
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
942.0 ±4.0 mm [37.1 ±0.16 in]
210.5 ±1.0 mm [8.3 ±0.04 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
9.0 ± 1.0 mm [0.4 ± 0.04 in]
685.0 ± 2.5 mm [27.0 ± 0.10 in]
757.6 ± 2.5 mm [29.8 ± 0.10 in]
984.6 ± 4.0 mm [38.8 ± 0.16 in]
Danfoss A/S © 10/2016 Alle Rechte vorbehalten.
369.3 ±2.5 mm [14.5 ±0.1 in]
418.0 ±2.5 mm [16.5 ±0.1 in]
210.50 ±1.0 mm [8.3 ±0.04 in]
84.6 ±2.5 mm [3.3 ±0.1 in]
MG80C503
