Danfoss VLT AHF 010 Projektierungshandbuch Seite 78

Spezifikationen
F1
F2
7 7
Abbildung 7.29 IP20 X5 Interner Lüfter 1
Abbildung 7.30 IP20 X5 Interner Lüfter 1, 3D-Ansicht
76
VLT
X1 Mains 50 mm 2
X2 Drive 50 mm 2
X3/X4 Capacitor disconnect 16 mm
A/B Temperature 2.5 mm
PE M8
210.5 ±1 mm [8.3 ±0.04 in]
63.8 ±2.5 mm [2.5 ±0.10 in]
9.0 ±1 mm [0.4 ±0.04 in]
Danfoss A/S © 10/2016 Alle Rechte vorbehalten.
®
Advanced Harmonic Filter AHF 005/AHF 010
2
2
597.0 ±2.5 mm [23.5 ±0.10 in]
240.0 ±1 mm [9.4 ±0.04 in]
9.0 ±1 mm [0.4 ±0.04 in]
685.0 ±2.5 mm [27.0 ±0.10 in]
736.8 ±2.5 mm [29.0 ±0.10 in]
370.0 ±2.5 mm [14.6 ±0.10 in]
418.0 ±2.5 mm [16.5± 0.10 in]
210.5 ±1 mm [8.3 ±0.04 in]
MG80C503
