Spezifikationen
242.6 ± 2.5 mm [9.5 ± 0.10 in]
7 7
9.0 ± 1.0 mm [0.4 ± 0.04 in]
Abbildung 7.93 IP21 X6 Interner Lüfter 1
Abbildung 7.94 IP21 X6 Interner Lüfter 1, 3D-Ansicht
108
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
922 ± 4.0 mm [36.3 ± 0.16 in]
210.5 ± 1.0 mm [8.3 ± 0.04 in]
240.0 ± 1.0 mm [9.4 ± 0.04 in]
9.0 ± 1.0 mm [0.4 ± 0.04 in]
685.0 ± 2.5 mm [27.0 ± 0.10 in]
737.6 ± 2.5 mm [29.0 ± 0.10 in]
964.6 ± 4.0 mm [38.0 ± 0.16 in]
Danfoss A/S © 10/2016 Alle Rechte vorbehalten.
370.0 ± 2.5 mm [14.6 ± 0.10 in]
418.0 ± 2.5 mm [16.5 ± 0.10 in]
210.5 ± 1.0 mm [8.3 ± 0.04 in]
64.6 ± 2.5 mm [2.5 ± 0.10 in]
MG80C503
