Spezifikationen
F1
F2
7 7
Abbildung 7.21 IP20 X4 Interner Lüfter 1
Abbildung 7.22 IP20 X4 Interner Lüfter 1, 3D-Ansicht
72
VLT
X1 Mains 35mm 2
X2 Drive 35mm 2
X3/X4 Capacitor disconnect 16mm
A/B Temperature 2.5mm
PE M8
157.0 ± 1 mm [6.2 ± 0.04 in]
9.0 ± 1 mm [0.4 ± 0.04 in]
54.3 ± 2.5 mm [2.1 ± 0.10 in]
Danfoss A/S © 10/2016 Alle Rechte vorbehalten.
®
Advanced Harmonic Filter AHF 005/AHF 010
2
2
489 ± 2.5 mm [19.3 ± 0.1 in]
240.0 ± 1 mm [9.4 ± 0.04 in]
9.0 ± 1 mm [0.4 ± 0.04 in]
577.0 ± 2.5 mm [22.7 ± 0.10 in]
579.0 ± 2.5 mm [22.8 ± 0.10 in]
619.8 ± 2.5 mm [24.4 ± 0.10 in]
330 ± 2.5 mm [13.0 ± 0.1 in]
157.0 ± 1 mm [6.2 ± 0.04 in]
