Spezifikationen
F1
F2
7 7
Abbildung 7.13 IP20 X3 Interner Lüfter 1
Abbildung 7.14 IP20 X3 Interner Lüfter 1, 3D-Ansicht
68
®
VLT
X1 Mains 16mm
2
X2 Drive 16mm 2
X3/X4 Capacitor disconnect 10mm
A/B Temperature 2.5mm
PE M8
145 ± 1 mm [5.7 ± 0.04 in]
9 ± 1 mm [0.4 ± 0.04 in]
Danfoss A/S © 10/2016 Alle Rechte vorbehalten.
Advanced Harmonic Filter AHF 005/AHF 010
2
2
460 ± 2.5 mm [18.1 ± 0.1 in]
233 ± 1 mm [9.2 ± 0.04 in]
9 ± 1 mm [0.4 ± 0.04 in]
547 ± 2.5 mm [21.5 ± 0.1 in]
550 ± 2.5 mm [21.6 ± 0.1 in]
590 ± 2.5 mm [23.2 ± 0.1 in]
330 ± 2.5 mm [13.0 ± 0.1 in]
145 ± 1 mm [5.7 ± 0.04 in]
MG80C503
